PESD5V0V1BA,115
INQUIRY ONLINE
|
Category
|
Circuit Protection
Transient Voltage Suppressors (TVS)
TVS Diodes
|
|
|
Mfr
|
Nexperia USA Inc.
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Type
|
Zener
|
|
|
Bidirectional Channels
|
1
|
|
|
Voltage – Reverse Standoff (Typ)
|
5V (Max)
|
|
|
Voltage – Breakdown (Min)
|
5.8V
|
|
|
Voltage – Clamping (Max) @ Ipp
|
12.5V
|
|
|
Current – Peak Pulse (10/1000µs)
|
4.8A (8/20µs)
|
|
|
Power – Peak Pulse
|
45W
|
|
|
Power Line Protection
|
No
|
|
|
Applications
|
–
|
|
|
Capacitance @ Frequency
|
11pF @ 1MHz
|
|
|
Operating Temperature
|
-55°C ~ 150°C (TA)
|
|
|
Grade
|
Automotive
|
|
|
Qualification
|
AEC-Q101
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
SC-76, SOD-323
|
|
|
Supplier Device Package
|
SOD-323
|
|
|
Base Product Number
|
PESD5
|
