SSM6J511NU,LF
INQUIRY ONLINE
|
Category
|
Discrete Semiconductor Products
Transistors
FETs, MOSFETs
Single FETs, MOSFETs
|
|
|
Mfr
|
Toshiba Semiconductor and Storage
|
|
|
Series
|
U-MOSVII
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
FET Type
|
P-Channel
|
|
|
Technology
|
MOSFET (Metal Oxide)
|
|
|
Drain to Source Voltage (Vdss)
|
12 V
|
|
|
Current – Continuous Drain (Id) @ 25°C
|
14A (Ta)
|
|
|
Rds On (Max) @ Id, Vgs
|
9.1mOhm @ 4A, 8V
|
|
|
Vgs(th) (Max) @ Id
|
1V @ 1mA
|
|
|
Gate Charge (Qg) (Max) @ Vgs
|
47 nC @ 4.5 V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds
|
3350 pF @ 6 V
|
|
|
FET Feature
|
–
|
|
|
Operating Temperature
|
-55°C ~ 150°C (TJ)
|
|
|
Grade
|
–
|
|
|
Qualification
|
–
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Supplier Device Package
|
6-UDFNB (2×2)
|
|
|
Package / Case
|
6-WDFN Exposed Pad
|
|
|
Base Product Number
|
SSM6J511
|
