SN74LVC541ADW
INQUIRY ONLINE
|
Category
|
Integrated Circuits (ICs)
Logic
Buffers, Drivers, Receivers, Transceivers
|
|
|
Manufacturer
|
Texas Instruments
|
|
|
Series
|
74LVC
|
|
|
Packaging
|
Tube
|
|
|
Part Status
|
Active
|
|
|
Logic Type
|
Buffer, Non-Inverting
|
|
|
Number of Elements
|
1
|
|
|
Number of Bits per Element
|
8
|
|
|
Input Type
|
–
|
|
|
Output Type
|
3-State
|
|
|
Current – Output High, Low
|
24mA, 24mA
|
|
|
Voltage – Supply
|
1.65V ~ 3.6V
|
|
|
Operating Temperature
|
-40°C ~ 125°C (TA)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
20-SOIC (0.295″, 7.50mm Width)
|
|
|
Supplier Device Package
|
20-SOIC
|
|
|
Base Product Number
|
74LVC541
|
