SGM8551XN5G/TR

The SGM8551XN is a single rail-to-rail input and output
precision operational amplifier which has low input offset
voltage, and bias current. It is guaranteed to operate from
2.5V to 5.5V single supply.
The rail-to-rail input and output swings provided by the
SGM8551XN make both high-side and low-side sensing
easy. The combination of characteristics makes the
SGM8551XN good choices for temperature, position and
pressure sensors, medical equipment and strain gauge
amplifiers, or any other 2.5V to 5.5V application requiring
precision and long term stability.
The SGM8551XN is specified for the extended industrial/
automotive (-40℃ to +125℃) temperature range. It is
available in the Green SOT-23-5 package.

Category: Amplifiers

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

EAR99

Unconfirmed

Automotive

Unknown

PPAP

Unknown

Precision Amplifier

Rail to Rail Input/Output

0.02@5V

2.5

5.5

0.000003(Typ)@5V

0.000019@5V

0.553@5V

Single

0.84@5V

53@5V

145

90 to 95

1.48

-40

125

Extended Industrial/Automotive

Tape and Reel

Mounting

Surface Mount

Package Height

1.15(Max)

Package Width

1.7(Max)

Package Length

3.02(Max)

PCB changed

Standard Package Name

SOT

Supplier Package

SOT-23

Lead Shape

Gull-wing

 Low Offset Voltage: 12μV (TYP) at +5V
 Rail-to-Rail Input and Output Swing
 2.5V to 5.5V Single Supply Operation
 Voltage Gain: 145dB (TYP) at +5V
 PSRR: 110dB (TYP)
 CMRR: 105dB (TYP)
 Ultra Low Input Bias Current: 19pA
 Low Supply Current: 465μA (TYP)
 Overload Recovery Time: 0.1ms (at VS = +5V)
 No External Capacitors Required
 -40℃ to +125℃ Operating Temperature Range
 Available in Green SOT-23-5 Package
