MBR60200PT_T0_00001
INQUIRY ONLINE
|
Category
|
Discrete Semiconductor Products
Diodes
Rectifiers
Diode Arrays
|
|
|
Manufacturer
|
Panjit International Inc.
|
|
|
Series
|
–
|
|
|
Packaging
|
Tube
|
|
|
Part Status
|
Active
|
|
|
Diode Configuration
|
1 Pair Common Cathode
|
|
|
Technology
|
Schottky
|
|
|
Voltage – DC Reverse (Vr) (Max)
|
200 V
|
|
|
Current – Average Rectified (Io) (per Diode)
|
30A
|
|
|
Voltage – Forward (Vf) (Max) @ If
|
900 mV @ 30 A
|
|
|
Speed
|
Fast Recovery =< 500ns, > 200mA (Io)
|
|
|
Current – Reverse Leakage @ Vr
|
50 µA @ 200 V
|
|
|
Operating Temperature – Junction
|
-65°C ~ 175°C
|
|
|
Mounting Type
|
Through Hole
|
|
|
Package / Case
|
TO-247-3
|
|
|
Supplier Device Package
|
TO-247AD (TO-3P)
|
|
|
Base Product Number
|
MBR60200
|
