HMLB25201B-R47MSR
INQUIRY ONLINE
|
Category
|
Inductors, Coils, Chokes
Fixed Inductors
|
|
|
Mfr
|
Delta Electronics/Cyntec
|
|
|
Series
|
HMLB25201B
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Obsolete
|
|
|
Type
|
–
|
|
|
Material – Core
|
Metal
|
|
|
Inductance
|
470 nH
|
|
|
Tolerance
|
±20%
|
|
|
Current Rating (Amps)
|
4.5 A
|
|
|
Current – Saturation (Isat)
|
4.55A
|
|
|
Shielding
|
Shielded
|
|
|
DC Resistance (DCR)
|
26mOhm Max
|
|
|
Q @ Freq
|
–
|
|
|
Frequency – Self Resonant
|
–
|
|
|
Ratings
|
–
|
|
|
Operating Temperature
|
-55°C ~ 125°C
|
|
|
Inductance Frequency – Test
|
1 MHz
|
|
|
Features
|
–
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
1008 (2520 Metric)
|
|
|
Supplier Device Package
|
1008
|
|
|
Size / Dimension
|
0.098″ L x 0.079″ W (2.50mm x 2.00mm)
|
|
|
Height – Seated (Max)
|
0.047″ (1.20mm)
|
|
|
Base Product Number
|
HMLB25201
|
