CDRH2D11 HPNP-2R2NC
INQUIRY ONLINE
|
Category
|
Inductors, Coils, Chokes
Fixed Inductors
|
|
|
Mfr
|
Sumida America Components Inc.
|
|
|
Series
|
CDRH2D11/HP
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Type
|
–
|
|
|
Material – Core
|
Ferrite
|
|
|
Inductance
|
2.2 µH
|
|
|
Tolerance
|
±30%
|
|
|
Current Rating (Amps)
|
1.3 A
|
|
|
Current – Saturation (Isat)
|
1.1A
|
|
|
Shielding
|
Shielded
|
|
|
DC Resistance (DCR)
|
120mOhm Max
|
|
|
Q @ Freq
|
–
|
|
|
Frequency – Self Resonant
|
–
|
|
|
Ratings
|
–
|
|
|
Operating Temperature
|
-40°C ~ 105°C
|
|
|
Inductance Frequency – Test
|
100 kHz
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
Nonstandard
|
|
|
Supplier Device Package
|
–
|
|
|
Size / Dimension
|
0.118″ L x 0.118″ W (3.00mm x 3.00mm)
|
|
|
Height – Seated (Max)
|
0.043″ (1.10mm)
|
