744272121
INQUIRY ONLINE
|
Category
|
Filters
Common Mode Chokes
|
|
|
Manufacturer
|
Würth Elektronik
|
|
|
Series
|
WE-SL5
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Filter Type
|
Power, Signal Line
|
|
|
Number of Lines
|
2
|
|
|
Impedance @ Frequency
|
460 Ohms @ 30 MHz
|
|
|
Inductance @ Frequency
|
120 µH @ 100 kHz
|
|
|
Current Rating (Max)
|
2.5A
|
|
|
DC Resistance (DCR) (Max)
|
25mOhm
|
|
|
Voltage Rating – DC
|
80V
|
|
|
Voltage Rating – AC
|
–
|
|
|
Operating Temperature
|
-40°C ~ 125°C
|
|
|
Ratings
|
–
|
|
|
Approval Agency
|
–
|
|
|
Features
|
–
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Size / Dimension
|
0.394″ L x 0.343″ W (10.00mm x 8.70mm)
|
|
|
Height (Max)
|
0.256″ (6.50mm)
|
|
|
Package / Case
|
Horizontal, 4 PC Pad
|
