Category |
Discrete Semiconductor Products
Transistors
Bipolar (BJT)
Single Bipolar Transistors
|
|
|
Mfr |
Diodes Incorporated |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Transistor Type |
PNP |
|
|
Current - Collector (Ic) (Max) |
4.3 A
|
|
|
Voltage - Collector Emitter Breakdown (Max) |
60 V
|
|
|
Vce Saturation (Max) @ Ib, Ic |
215mV @ 500mA, 5A
|
|
|
Current - Collector Cutoff (Max) |
20nA (ICBO)
|
|
|
DC Current Gain (hFE) (Min) @ Ic, Vce |
100 @ 2A, 1V
|
|
|
Power - Max |
2.1 W
|
|
|
Frequency - Transition |
120MHz
|
|
|
Operating Temperature |
-55°C ~ 150°C (TJ)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
TO-243AA
|
|
|
Supplier Device Package |
SOT-89-3
|
|
|
Base Product Number |
ZXTP2012 |
