Category |
RF and Wireless
RF Antennas
|
|
|
Manufacturer |
Pulse Electronics
|
|
|
Series |
-
|
|
|
Packaging |
Bulk
|
|
|
Part Status |
Active
|
|
|
RF Family/Standard |
802.15.4, Bluetooth, WiFi
|
|
|
Frequency Group |
UHF (2GHz ~ 3GHz), SHF (f > 4GHz)
|
|
|
Frequency (Center/Band) |
2.4GHz, 5GHz
|
|
|
Frequency Range |
2.4GHz ~ 2.5GHz, 4.9GHz ~ 5.825GHz
|
|
|
Antenna Type |
Whip, Tilt
|
|
|
Number of Bands |
2
|
|
|
VSWR |
2
|
|
|
Return Loss |
-
|
|
|
Gain |
2.5dBi, 3.5dBi
|
|
|
Features |
-
|
|
|
Termination |
RP-SMA Male
|
|
|
Ingress Protection |
-
|
|
|
Mounting Type |
Connector Mount
|
|
|
Height (Max) |
6.201" (157.50mm)
|
|
|
Applications |
Bluetooth, WLAN, Zigbee™
|
