Category |
Circuit Protection
Transient Voltage Suppressors (TVS)
TVS Diodes
|
|
|
Mfr |
Littelfuse Inc. |
|
|
Series |
TPSMB |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Zener
|
|
|
Unidirectional Channels |
1
|
|
|
Voltage - Reverse Standoff (Typ) |
13.6V
|
|
|
Voltage - Breakdown (Min) |
15.2V
|
|
|
Voltage - Clamping (Max) @ Ipp |
22.5V
|
|
|
Current - Peak Pulse (10/1000µs) |
27.1A
|
|
|
Power - Peak Pulse |
600W
|
|
|
Power Line Protection |
No
|
|
|
Applications |
-
|
|
|
Capacitance @ Frequency |
-
|
|
|
Operating Temperature |
-65°C ~ 175°C (TJ)
|
|
|
Grade |
Automotive
|
|
|
Qualification |
AEC-Q101
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
DO-214AA, SMB
|
|
|
Supplier Device Package |
DO-214AA (SMBJ) |
