Category |
Circuit Protection
Transient Voltage Suppressors (TVS)
TVS Diodes
|
|
|
Mfr |
Texas Instruments |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Zener
|
|
|
Unidirectional Channels |
1
|
|
|
Voltage - Reverse Standoff (Typ) |
5.5V (Max)
|
|
|
Voltage - Breakdown (Min) |
6.4V
|
|
|
Voltage - Clamping (Max) @ Ipp |
14V (Typ)
|
|
|
Current - Peak Pulse (10/1000µs) |
2.5A (8/20µs)
|
|
|
Power - Peak Pulse |
30W
|
|
|
Power Line Protection |
Yes
|
|
|
Applications |
HDMI, USB
|
|
|
Capacitance @ Frequency |
0.42pF @ 1MHz
|
|
|
Operating Temperature |
-40°C ~ 125°C (TA)
|
|
|
Grade |
Automotive
|
|
|
Qualification |
AEC-Q101
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
0402 (1006 Metric)
|
|
|
Supplier Device Package |
2-X1SON (1x.60) |
|
|
Base Product Number |
TPD1E05U06 |
