Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Gate Drivers
|
|
|
Manufacturer |
Microchip Technology
|
|
|
Series |
-
|
|
|
Packaging |
Tube
|
|
|
Part Status |
Active
|
|
|
DigiKey Programmable |
Not Verified
|
|
|
Driven Configuration |
Low-Side
|
|
|
Channel Type |
Independent
|
|
|
Number of Drivers |
2
|
|
|
Gate Type |
N-Channel, P-Channel MOSFET
|
|
|
Voltage - Supply |
4.5V ~ 18V
|
|
|
Logic Voltage - VIL, VIH |
0.8V, 2.4V
|
|
|
Current - Peak Output (Source, Sink) |
1.5A, 1.5A
|
|
|
Input Type |
Non-Inverting
|
|
|
Rise / Fall Time (Typ) |
19ns, 19ns
|
|
|
Operating Temperature |
0°C ~ 70°C (TA)
|
|
|
Mounting Type |
Through Hole
|
|
|
Package / Case |
8-DIP (0.300", 7.62mm)
|
|
|
Supplier Device Package |
8-PDIP
|
|
|
Base Product Number |
TC4427 |
