Category |
Integrated Circuits (ICs)
Logic
Buffers, Drivers, Receivers, Transceivers
|
|
|
Manufacturer |
Texas Instruments
|
|
|
Series |
-
|
|
|
Packaging |
Tube
|
|
|
Part Status |
Active
|
|
|
Logic Type |
Buffer, Inverting
|
|
|
Number of Elements |
6
|
|
|
Number of Bits per Element |
1
|
|
|
Input Type |
-
|
|
|
Output Type |
Open Collector
|
|
|
Current - Output High, Low |
250µA, 30mA
|
|
|
Voltage - Supply |
4.5V ~ 5.5V
|
|
|
Operating Temperature |
-55°C ~ 125°C (TA)
|
|
|
Mounting Type |
Through Hole
|
|
|
Package / Case |
14-CDIP (0.300", 7.62mm)
|
|
|
Supplier Device Package |
14-CDIP
|
