Category |
Circuit Protection
Transient Voltage Suppressors (TVS)
TVS Diodes
|
|
|
Mfr |
Nexperia USA Inc. |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Zener
|
|
|
Bidirectional Channels |
1
|
|
|
Voltage - Reverse Standoff (Typ) |
5.5V (Max)
|
|
|
Voltage - Breakdown (Min) |
6V
|
|
|
Voltage - Clamping (Max) @ Ipp |
15V
|
|
|
Current - Peak Pulse (10/1000µs) |
2.5A (8/20µs)
|
|
|
Power - Peak Pulse |
-
|
|
|
Power Line Protection |
No
|
|
|
Applications |
-
|
|
|
Capacitance @ Frequency |
0.4pF @ 1MHz
|
|
|
Operating Temperature |
-40°C ~ 125°C (TA)
|
|
|
Grade |
Automotive
|
|
|
Qualification |
AEC-Q101
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
SOD-882
|
|
|
Supplier Device Package |
DFN1006-2 |
|
|
Base Product Number |
PESD5 |
