Category |
Discrete Semiconductor Products
Transistors
Bipolar (BJT)
Single, Pre-Biased Bipolar Transistors
|
|
|
Manufacturer |
onsemi
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Transistor Type |
NPN - Pre-Biased
|
|
|
Current - Collector (Ic) (Max) |
100 mA
|
|
|
Voltage - Collector Emitter Breakdown (Max) |
50 V
|
|
|
Resistors Included |
R1 and R2
|
|
|
Resistor - Base (R1) |
4.7 kOhms
|
|
|
Resistor - Emitter Base (R2) |
47 kOhms
|
|
|
DC Current Gain (hFE) (Min) @ Ic, Vce |
80 @ 5mA, 10V
|
|
|
Vce Saturation (Max) @ Ib, Ic |
250mV @ 300µA, 10mA
|
|
|
Current - Collector Cutoff (Max) |
500nA
|
|
|
Power - Max |
246 mW
|
|
|
Grade |
-
|
|
|
Qualification |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
TO-236-3, SC-59, SOT-23-3
|
|
|
Supplier Device Package |
SOT-23-3 (TO-236)
|
|
|
Base Product Number |
MMUN2233 |
