Category |
Discrete Semiconductor Products
Transistors
Bipolar (BJT)
Single Bipolar Transistors
|
|
|
Mfr |
onsemi |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Transistor Type |
NPN |
|
|
Current - Collector (Ic) (Max) |
600 mA
|
|
|
Voltage - Collector Emitter Breakdown (Max) |
40 V
|
|
|
Vce Saturation (Max) @ Ib, Ic |
1V @ 50mA, 500mA
|
|
|
Current - Collector Cutoff (Max) |
10nA (ICBO)
|
|
|
DC Current Gain (hFE) (Min) @ Ic, Vce |
100 @ 150mA, 10V
|
|
|
Power - Max |
225 mW
|
|
|
Frequency - Transition |
300MHz
|
|
|
Operating Temperature |
-55°C ~ 150°C (TJ)
|
|
|
Grade |
Automotive
|
|
|
Qualification |
AEC-Q101
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
TO-236-3, SC-59, SOT-23-3
|
|
|
Supplier Device Package |
SOT-23-3 (TO-236)
|
|
|
Base Product Number |
MMBT2222 |
