Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - DC DC Switching Regulators
|
|
|
Mfr |
Analog Devices Inc. |
|
|
Series |
Silent Switcher®2 |
|
|
Packaging |
Tray
|
|
|
Part Status |
Active
|
|
|
Function |
Step-Down
|
|
|
Output Configuration |
Positive
|
|
|
Topology |
Buck |
|
|
Output Type |
Adjustable |
|
|
Number of Outputs |
2
|
|
|
Voltage - Input (Min) |
2.6V
|
|
|
Voltage - Input (Max) |
42V
|
|
|
Voltage - Output (Min/Fixed) |
0.8V |
|
|
Voltage - Output (Max) |
42V
|
|
|
Current - Output |
4A |
|
|
Frequency - Switching |
300kHz ~ 3MHz
|
|
|
Synchronous Rectifier |
Yes
|
|
|
Operating Temperature |
-40°C ~ 125°C (TJ)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
32-TFQFN Exposed Pad, 28 Leads |
|
|
Supplier Device Package |
32-LQFN (6x4)
|
|
|
Base Product Number |
LT8650 |
