Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
|
|
|
Mfr |
Analog Devices Inc. |
|
|
Series |
-
|
|
|
Packaging |
Tube
|
|
|
Part Status |
Active
|
|
|
Output Configuration |
Positive |
|
|
Output Type |
Adjustable |
|
|
Number of Regulators |
1
|
|
|
Voltage - Input (Max) |
45V
|
|
|
Voltage - Output (Min/Fixed) |
0.6V
|
|
|
Voltage - Output (Max) |
40V |
|
|
Voltage Dropout (Max) |
0.53V @ 200mA
|
|
|
Current - Output |
200mA |
|
|
Current - Quiescent (Iq) |
90 µA
|
|
|
Current - Supply (Max) |
10 mA
|
|
|
PSRR |
85dB (120Hz)
|
|
|
Control Features |
Soft Start
|
|
|
Protection Features |
Over Current, Over Temperature, Reverse Polarity
|
|
|
Operating Temperature |
-40°C ~ 150°C
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
|
|
|
Supplier Device Package |
8-MSOP-EP
|
|
|
Base Product Number |
LT3062 |
