Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
|
|
|
Mfr |
Analog Devices Inc. |
|
|
Series |
-
|
|
|
Packaging |
Tube
|
|
|
Part Status |
Active
|
|
|
Output Configuration |
Positive |
|
|
Output Type |
Fixed |
|
|
Number of Regulators |
1
|
|
|
Voltage - Input (Max) |
25V
|
|
|
Voltage - Output (Min/Fixed) |
12V
|
|
|
Voltage - Output (Max) |
-
|
|
|
Voltage Dropout (Max) |
1.5V @ 1.5A
|
|
|
Current - Output |
1.5A |
|
|
Current - Quiescent (Iq) |
10 mA
|
|
|
PSRR |
60dB (120Hz)
|
|
|
Control Features |
-
|
|
|
Protection Features |
Over Current, Over Temperature
|
|
|
Operating Temperature |
0°C ~ 125°C
|
|
|
Mounting Type |
Through Hole
|
|
|
Package / Case |
TO-220-3
|
|
|
Supplier Device Package |
TO-220-3
|
|
|
Base Product Number |
LT1086 |
