LQH2HPZ220MJRL
零件编号：
LQH2HPZ220MJRL
产品分类：
按钮开关 - 霍尔效应
制造商：
AerosUSA
描述：
FIXED IND 22UH 540MA 1.008OHM SM
包装：
-
ROHS状态：
No
货币：
USD
PDF：
资料
|
Category |
Inductors, Coils, Chokes
Fixed Inductors
|
|
|
Mfr |
Murata Electronics |
|
|
Series |
LQH2 |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Drum Core, Wirewound
|
|
|
Material - Core |
Ferrite |
|
|
Inductance |
22 µH
|
|
|
Tolerance |
±20%
|
|
|
Current Rating (Amps) |
540 mA |
|
|
Current - Saturation (Isat) |
530mA
|
|
|
Shielding |
Shielded
|
|
|
DC Resistance (DCR) |
1.008Ohm Max
|
|
|
Frequency - Self Resonant |
20MHz
|
|
|
Ratings |
AEC-Q200
|
|
|
Operating Temperature |
-40°C ~ 105°C
|
|
|
Inductance Frequency - Test |
1 MHz
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
1008 (2520 Metric)
|
|
|
Supplier Device Package |
1008 (2520 Metric)
|
|
|
Size / Dimension |
0.098" L x 0.079" W (2.50mm x 2.00mm)
|
|
|
Height - Seated (Max) |
0.039" (1.00mm)
|
|
|
Base Product Number |
LQH2HPZ |
