Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - DC DC Switching Regulators
|
|
|
Mfr |
Texas Instruments |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Function |
Step-Down
|
|
|
Output Configuration |
Positive
|
|
|
Topology |
Buck |
|
|
Output Type |
Adjustable |
|
|
Number of Outputs |
1
|
|
|
Voltage - Input (Min) |
3V
|
|
|
Voltage - Input (Max) |
36V
|
|
|
Voltage - Output (Min/Fixed) |
1V |
|
|
Voltage - Output (Max) |
34.2V
|
|
|
Current - Output |
8A |
|
|
Frequency - Switching |
400kHz, 2.2MHz, 200kHz ~ 2.2MHz
|
|
|
Synchronous Rectifier |
Yes
|
|
|
Operating Temperature |
-40°C ~ 150°C (TJ)
|
|
|
Grade |
Automotive
|
|
|
Qualification |
AEC-Q100
|
|
|
Mounting Type |
Surface Mount, Wettable Flank
|
|
|
Package / Case |
16-PowerVFQFN |
|
|
Supplier Device Package |
16-VQFN-HR (4.5x3.5)
|
|
|
Base Product Number |
LM61480 |
