Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
|
|
|
Mfr |
STMicroelectronics |
|
|
Series |
-
|
|
|
Packaging |
Tube
|
|
|
Part Status |
Obsolete
|
|
|
Output Configuration |
Positive |
|
|
Output Type |
Fixed |
|
|
Number of Regulators |
1
|
|
|
Voltage - Input (Max) |
35V
|
|
|
Voltage - Output (Min/Fixed) |
9V
|
|
|
Voltage - Output (Max) |
-
|
|
|
Voltage Dropout (Max) |
2V @ 1A (Typ)
|
|
|
Current - Output |
1.5A |
|
|
Current - Quiescent (Iq) |
8 mA
|
|
|
PSRR |
55dB (120Hz)
|
|
|
Control Features |
-
|
|
|
Protection Features |
Over Temperature, Short Circuit
|
|
|
Operating Temperature |
0°C ~ 125°C
|
|
|
Mounting Type |
Through Hole
|
|
|
Package / Case |
TO-220-3
|
|
|
Supplier Device Package |
TO-220
|
|
|
Base Product Number |
L7809 |
