Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Gate Drivers
|
|
|
Manufacturer |
Infineon Technologies
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
DigiKey Programmable |
Not Verified
|
|
|
Driven Configuration |
Half-Bridge
|
|
|
Channel Type |
3-Phase
|
|
|
Number of Drivers |
6
|
|
|
Gate Type |
IGBT, N-Channel MOSFET
|
|
|
Voltage - Supply |
10V ~ 20V
|
|
|
Logic Voltage - VIL, VIH |
0.8V, 2V
|
|
|
Current - Peak Output (Source, Sink) |
250mA, 500mA
|
|
|
Input Type |
Inverting
|
|
|
High Side Voltage - Max (Bootstrap) |
1200 V
|
|
|
Rise / Fall Time (Typ) |
90ns, 40ns
|
|
|
Operating Temperature |
125°C (TJ)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
44-LCC (J-Lead), 32 Leads
|
|
|
Supplier Device Package |
44-PLCC, 32 Leads (16.58x16.58)
|
|
|
Base Product Number |
IR2233 |
