Category |
Connectors, Interconnects
Terminal Blocks
Headers, Plugs and Sockets
|
|
|
Manufacturer |
Dinkle Corporation, USA
|
|
|
Series |
EC381V |
|
|
Packaging |
Bulk
|
|
|
Part Status |
Active
|
|
|
Type |
Plug, Female Sockets
|
|
|
Number of Positions |
2
|
|
|
Positions Per Level |
2
|
|
|
Number of Levels |
1
|
|
|
Pitch |
0.150" (3.81mm)
|
|
|
Header Orientation |
-
|
|
|
Plug Wire Entry |
180°
|
|
|
Termination Style |
Screw
|
|
|
Mounting Type |
Free Hanging (In-Line)
|
|
|
Current - IEC |
14A
|
|
|
Voltage - IEC |
320 V
|
|
|
Current - UL |
8 A
|
|
|
Voltage - UL |
300 V
|
|
|
Wire Gauge or Range - AWG |
14-28 AWG
|
|
|
Wire Gauge or Range - mm² |
0.2-1.5mm²
|
|
|
Color |
Green
|
|
|
Operating Temperature |
-40°C ~ 120°C
|
|
|
Contact Mating Finish |
Tin
|
|
|
Features |
-
|
|
|
Material Flammability Rating |
UL94 V-0
|
|
|
Ingress Protection |
-
|
|
|
Screw Size |
M2
|
|
|
Torque - Screw |
0.2 Nm (1.7 Lb-In)
|
|
|
Wire Strip Length |
6-7mm
|
|
|
Contact Material |
Copper Alloy
|
|
|
Housing Material |
Polyamide (PA), Nylon
|
|
|
Contact Tail Length |
-
|
|
|
Insulation Height |
0.437" (11.10mm)
|
