Category |
Discrete Semiconductor Products
Transistors
FETs, MOSFETs
FET, MOSFET Arrays
|
|
|
Manufacturer |
Diodes Incorporated
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Technology |
MOSFET (Metal Oxide)
|
|
|
Configuration |
2 P-Channel (Dual) Common Drain
|
|
|
FET Feature |
Logic Level Gate
|
|
|
Drain to Source Voltage (Vdss) |
20V
|
|
|
Current - Continuous Drain (Id) @ 25°C |
6.04A
|
|
|
Rds On (Max) @ Id, Vgs |
35mOhm @ 4A, 4.5V
|
|
|
Vgs(th) (Max) @ Id |
1V @ 250µA
|
|
|
Gate Charge (Qg) (Max) @ Vgs |
15.4nC @ 4.5V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds |
1610pF @ 10V
|
|
|
Power - Max |
890mW
|
|
|
Operating Temperature |
-55°C ~ 150°C (TJ)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
8-TSSOP (0.173", 4.40mm Width)
|
|
|
Supplier Device Package |
8-TSSOP
|
|
|
Base Product Number |
DMP2035 |
