Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Power Distribution Switches, Load Drivers
|
|
|
Mfr |
Diodes Incorporated |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Switch Type |
General Purpose |
|
|
Number of Outputs |
1
|
|
|
Ratio - Input:Output |
1:1
|
|
|
Output Configuration |
High Side
|
|
|
Output Type |
N-Channel
|
|
|
Interface |
On/Off
|
|
|
Voltage - Load |
0.5V ~ 13.5V
|
|
|
Voltage - Supply (Vcc/Vdd) |
3V ~ 5.5V
|
|
|
Current - Output (Max) |
20A
|
|
|
Rds On (Typ) |
6.1mOhm
|
|
|
Input Type |
Non-Inverting
|
|
|
Features |
-
|
|
|
Fault Protection |
Short-Circuit, Thermal Shutdown, UVLO
|
|
|
Operating Temperature |
-40°C ~ 85°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Supplier Device Package |
V-DFN3030-12 (Type B)
|
|
|
Package / Case |
12-VFDFN Exposed Pad |
|
|
Base Product Number |
DML3009 |
