Category |
Power Supplies - Board Mount
DC DC Converters
|
|
|
Mfr |
Texas Instruments |
|
|
Series |
DCP01B (1W) |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Isolated Module
|
|
|
Number of Outputs |
1
|
|
|
Voltage - Input (Min) |
4.5V
|
|
|
Voltage - Input (Max) |
5.5V
|
|
|
Voltage - Output 1 |
5V |
|
|
Voltage - Output 2 |
-
|
|
|
Voltage - Output 3 |
-
|
|
|
Current - Output (Max) |
200mA
|
|
|
Power (Watts) |
1 W
|
|
|
Voltage - Isolation |
1 kV
|
|
|
Applications |
ITE (Commercial)
|
|
|
Features |
OTP, SCP
|
|
|
Operating Temperature |
-40°C ~ 100°C
|
|
|
Efficiency |
80%
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
14-SMD Module, 7 Leads
|
|
|
Size / Dimension |
0.78" L x 0.33" W x 0.21" H (19.7mm x 8.3mm x 5.3mm)
|
|
|
Control Features |
Enable, Active High
|
|
|
Base Product Number |
DCP010505 |
