Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Battery Chargers
|
|
|
Manufacturer |
Texas Instruments
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Battery Chemistry |
Lithium Ion/Polymer
|
|
|
Number of Cells |
1
|
|
|
Current - Charging |
Constant - Programmable
|
|
|
Programmable Features |
Current
|
|
|
Fault Protection |
Over Temperature, Over Voltage, Short Circuit
|
|
|
Charge Current - Max |
1A
|
|
|
Battery Pack Voltage |
4.2V
|
|
|
Voltage - Supply (Max) |
28V
|
|
|
Interface |
-
|
|
|
Operating Temperature |
-40°C ~ 85°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
10-WFDFN Exposed Pad
|
|
|
Supplier Device Package |
10-WSON (2x2)
|
|
|
Base Product Number |
BQ24040 |
