Category |
Integrated Circuits (ICs)
Power Management (PMIC)
LED Drivers
|
|
|
Manufacturer |
Diodes Incorporated
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
DC DC Regulator
|
|
|
Topology |
Step-Down (Buck)
|
|
|
Internal Switch(s) |
Yes
|
|
|
Number of Outputs |
1
|
|
|
Voltage - Supply (Min) |
4.5V
|
|
|
Voltage - Supply (Max) |
40V
|
|
|
Voltage - Output |
36V
|
|
|
Current - Output / Channel |
1.5A
|
|
|
Frequency |
1MHz
|
|
|
Dimming |
Analog, PWM
|
|
|
Applications |
Backlight, Lighting, Signage
|
|
|
Operating Temperature |
-40°C ~ 85°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
SOT-89-5/6
|
|
|
Supplier Device Package |
SOT-89-5
|
|
|
Base Product Number |
AL8861 |
