Category |
RF and Wireless
RF Switches
|
|
|
Manufacturer |
Analog Devices Inc.
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
RF Type |
VSAT
|
|
|
Topology |
Absorptive
|
|
|
Circuit |
SPDT
|
|
|
Frequency Range |
100MHz ~ 30GHz
|
|
|
Isolation |
65dB
|
|
|
Insertion Loss |
2dB
|
|
|
Test Frequency |
20GHz
|
|
|
P1dB |
28dBm
|
|
|
IIP3 |
52dBm
|
|
|
Features |
-
|
|
|
Impedance |
50Ohm
|
|
|
Voltage - Supply |
5.5V
|
|
|
Operating Temperature |
-40°C ~ 85°C
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
20-WFLGA Exposed Pad
|
|
|
Supplier Device Package |
20-LGA (3x3)
|
|
|
Base Product Number |
ADRF5020 |
