TS12A12511DCNR
Part Number:
TS12A12511DCNR
Product Classification:
Accessories
Manufacturer:
3PEAK
Description:
IC SWITCH SPDT X 1 5OHM SOT23-8
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Interface
Analog Switches, Multiplexers, Demultiplexers
|
|
|
Manufacturer |
Texas Instruments
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Switch Circuit |
SPDT
|
|
|
Multiplexer/Demultiplexer Circuit |
2:1
|
|
|
Number of Circuits |
1
|
|
|
On-State Resistance (Max) |
5Ohm (Typ)
|
|
|
Channel-to-Channel Matching (ΔRon) |
1Ohm
|
|
|
Voltage - Supply, Single (V+) |
2.7V ~ 12V
|
|
|
Voltage - Supply, Dual (V±) |
±2.7V ~ 6V
|
|
|
Switch Time (Ton, Toff) (Max) |
95ns, 50ns
|
|
|
-3db Bandwidth |
93MHz
|
|
|
Charge Injection |
26pC
|
|
|
Channel Capacitance (CS(off), CD(off)) |
14pF
|
|
|
Current - Leakage (IS(off)) (Max) |
1nA
|
|
|
Crosstalk |
-70dB @ 1MHz
|
|
|
Operating Temperature |
-40°C ~ 85°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
SOT-23-8
|
|
|
Supplier Device Package |
SOT-23-8
|
|
|
Base Product Number |
TS12A12511 |
