TMUXHS4212IRKSR
Part Number:
TMUXHS4212IRKSR
Product Classification:
Wire Cutters
Manufacturer:
3PEAK
Description:
IC SW DPST, SPDTX2 8.4OHM 20VQFN
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Interface
Analog Switches, Multiplexers, Demultiplexers
|
|
|
Manufacturer |
Texas Instruments
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Switch Circuit |
DPST, SPDT
|
|
|
Multiplexer/Demultiplexer Circuit |
1:2, 2:1
|
|
|
Number of Circuits |
2
|
|
|
On-State Resistance (Max) |
8.4Ohm
|
|
|
Channel-to-Channel Matching (ΔRon) |
500mOhm
|
|
|
Voltage - Supply, Single (V+) |
1.71V ~ 1.98V, 3V ~ 3.6V
|
|
|
Voltage - Supply, Dual (V±) |
-
|
|
|
Switch Time (Ton, Toff) (Max) |
100ns, 100ns
|
|
|
-3db Bandwidth |
13GHz
|
|
|
Charge Injection |
-
|
|
|
Channel Capacitance (CS(off), CD(off)) |
-
|
|
|
Current - Leakage (IS(off)) (Max) |
5µA
|
|
|
Crosstalk |
-27dB @ 10GHz
|
|
|
Operating Temperature |
-40°C ~ 105°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
20-VFQFN Exposed Pad
|
|
|
Supplier Device Package |
20-VQFN (4.5x2.5)
|
