SRP5030CA-1R2M
Part Number:
SRP5030CA-1R2M
Product Classification:
Pushbutton Switches - Hall Effect
Manufacturer:
Almit (ANA TRADING)
Description:
FIXED IND 1.2UH 11A 9.7 MOHM SMD
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Inductors, Coils, Chokes
Fixed Inductors
|
|
|
Mfr |
Bourns Inc. |
|
|
Series |
SRP5030CA |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Drum Core, Wirewound
|
|
|
Material - Core |
Iron Powder |
|
|
Inductance |
1.2 µH
|
|
|
Tolerance |
±20%
|
|
|
Current Rating (Amps) |
11 A |
|
|
Current - Saturation (Isat) |
15A
|
|
|
Shielding |
Shielded
|
|
|
DC Resistance (DCR) |
9.7mOhm Max
|
|
|
Q @ Freq |
-
|
|
|
Frequency - Self Resonant |
43MHz
|
|
|
Ratings |
AEC-Q200
|
|
|
Operating Temperature |
-55°C ~ 155°C
|
|
|
Inductance Frequency - Test |
100 kHz
|
|
|
Features |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
Nonstandard
|
|
|
Supplier Device Package |
-
|
|
|
Size / Dimension |
0.217" L x 0.209" W (5.50mm x 5.30mm)
|
|
|
Height - Seated (Max) |
0.122" (3.10mm)
|
|
|
Base Product Number |
SRP5030CA |
