SN74LS04DR
Part Number:
SN74LS04DR
Product Classification:
Accessories - Boots, Seals
Manufacturer:
3PEAK
Description:
IC INVERTER 6CH 1-INP 14SOIC
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Logic
Gates and Inverters
|
|
|
Mfr |
Texas Instruments |
|
|
Series |
74LS |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Logic Type |
Inverter |
|
|
Number of Circuits |
6
|
|
|
Number of Inputs |
1
|
|
|
Features |
-
|
|
|
Voltage - Supply |
4.75V ~ 5.25V
|
|
|
Current - Output High, Low |
400µA, 8mA
|
|
|
Input Logic Level - Low |
0.8V
|
|
|
Input Logic Level - High |
2V
|
|
|
Max Propagation Delay @ V, Max CL |
15ns @ 5V, 15pF
|
|
|
Operating Temperature |
0°C ~ 70°C
|
|
|
Mounting Type |
Surface Mount
|
|
|
Supplier Device Package |
14-SOIC
|
|
|
Package / Case |
14-SOIC (0.154", 3.90mm Width)
|
|
|
Base Product Number |
74LS04 |
