SN74HC595DR

• 8-bit serial-in, parallel-out shift
• Wide operating voltage range of 2 V to 6 V
• High-current 3-state outputs can drive up to 15
LSTTL loads
• Low power consumption: 80-μA (maximum) ICC
• tpd = 13 ns (typical)
• ±6-mA output drive at 5 V
• Low input current: 1 μA (maximum)
• Shift register has direct clear
• On products compliant to MIL-PRF-38535,
all parameters are tested unless otherwise noted.
On all other products, production processing does
not necessarily include testing of all parameters.
