SN65DP159RGZ

• AC-coupled TMDS or DisplayPort Dual-Mode
Physical Layer Input to HDMI2.0b TMDS Physical
Layer Output Supporting up to 6 Gbps Data Rate,
Compatible with HDMI2.0b Electrical Parameters
• Supporting DisplayPort Dual-Mode Standard
Version 1.1
• Adaptive Receiver Equalizer and Programmable
Fixed Equalizer up to 16.5 dB
• High Speed Lane Control, Pre-emphasis and
Transmit Swing, and Slew Rate Control
• I
2C or Pin Strap Programmable
• Supports Type-2 I2C-over-AUX to DDC Bridge
• Integrated TMDS Level Translator and CDR
• Active I
2C[4] Buffer
• Input Swap on Main Lanes
• Low Power Consumption
• Low Power Consumption
– –435 mW Active at 6-Gbps and –10 mW at
Shutdown State
• Both Extended Commercial and Industrial
Temperature Device Options
• 40-pin, 0.4 mm Pitch, 5 mm x 5 mm, WQFN
Package, Pin Compatible to the TPD158 Redriver
• 40-pin, 0.5 mm Pitch, 7 mm x 7 mm, VQFN
Package
