SI1308EDL-T1-GE3
Part Number:
SI1308EDL-T1-GE3
Product Classification:
Solid State Relays (SSR)
Manufacturer:
ADSANTEC
Description:
Trans MOSFET N-CH 30V 1.4A 3-Pin SC-70 T/R
Packaging:
-
ROHS Status:
No
Currency:
USD
| Mfr | Vishay Siliconix |
| Series | TrenchFET® |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 1.4A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 10V |
| Rds On (Max) @ Id, Vgs | 132mOhm @ 1.4A, 10V |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 4.1 nC @ 10 V |
| Vgs (Max) | ±12V |
| Input Capacitance (Ciss) (Max) @ Vds | 105 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 400mW (Ta), 500mW (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SC-70-3 |
| Package / Case | SC-70, SOT-323 |
| Base Product Number | SI1308 |
