RTL8211F(I)-CG
Part Number:
RTL8211F(I)-CG
Product Classification:
Accessories
Manufacturer:
AC Electronics
Description:
PHY 1-CH 10Mbps/100Mbps/1Gbps 3.3V 40-Pin QFN EP
Packaging:
-
ROHS Status:
No
Currency:
USD
- 1000Base-T IEEE 802.3ab compatible
- 100Base-TX IEEE 802.3u compatible
- 10Base-T IEEE 802.3 compatible
- Supports RGMII
- Supports IEEE 802.3az-2010 (Energy Efficient Ethernet)
- Built-in Wake-on-LAN (WOL)
- Supports Interrupt function
- Supports Parallel Detection
- Crossover Detection & Auto-Correction
- Automatic polarity correction
- Supports PHYRSTB core power Turn-Off
- Baseline Wander Correction
- Supports 120m for CAT.5 cable in 1000Base-T
- Selectable 3.3/2.5/1.8/1.5V signaling for RGMII
- Supports 25MHz external crystal or OSC
- Provides 125MHz clock source for MAC
- Provides 3 network status LEDs
- Supports Link Down power saving
- Green Ethernet (1000/100Mbps mode only)
- Built-in Switching Regulator
- 40-pin QFN Green package
- 55 nm process with ultra-low power consumption
- Industrial grade manufacturing process (RTL8211FI-CG)
