PA5432.682NLT
Part Number:
PA5432.682NLT
Product Classification:
Pushbutton Switches - Hall Effect
Manufacturer:
Amerway Inc.
Description:
FIXED IND 6.8UH 9A 20.8MOHM SMD
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Inductors, Coils, Chokes
Fixed Inductors
|
|
|
Mfr |
Pulse Electronics |
|
|
Series |
PA5432.XXXNLT |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
-
|
|
|
Material - Core |
-
|
|
|
Inductance |
6.8 µH
|
|
|
Tolerance |
±20%
|
|
|
Current Rating (Amps) |
9 A |
|
|
Shielding |
Shielded
|
|
|
DC Resistance (DCR) |
20.8mOhm Max
|
|
|
Q @ Freq |
-
|
|
|
Frequency - Self Resonant |
18MHz
|
|
|
Ratings |
-
|
|
|
Operating Temperature |
-55°C ~ 155°C
|
|
|
Inductance Frequency - Test |
100 kHz
|
|
|
Features |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
Nonstandard
|
|
|
Supplier Device Package |
-
|
|
|
Size / Dimension |
0.268" L x 0.260" W (6.80mm x 6.60mm)
|
|
|
Height - Seated (Max) |
0.236" (6.00mm)
|
