NCP161AMX300TBG
Part Number:
NCP161AMX300TBG
Product Classification:
Keylock Switches
Manufacturer:
ADDA USA
Description:
IC REG LINEAR 3V 450MA 4XDFN
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
|
|
|
Mfr |
onsemi |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Output Configuration |
Positive |
|
|
Output Type |
Fixed |
|
|
Number of Regulators |
1
|
|
|
Voltage - Input (Max) |
5.5V
|
|
|
Voltage - Output (Min/Fixed) |
3V
|
|
|
Voltage - Output (Max) |
-
|
|
|
Voltage Dropout (Max) |
0.275V @ 450mA
|
|
|
Current - Output |
450mA |
|
|
Current - Quiescent (Iq) |
23 µA
|
|
|
PSRR |
91dB ~ 48dB (100Hz ~ 100kHz)
|
|
|
Control Features |
Enable
|
|
|
Protection Features |
Over Current, Over Temperature, Soft Start
|
|
|
Operating Temperature |
-40°C ~ 125°C
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
4-XDFN Exposed Pad
|
|
|
Supplier Device Package |
4-XDFN (1x1)
|
|
|
Base Product Number |
NCP161 |
