NCP1251BSN65T1G
Part Number:
NCP1251BSN65T1G
Product Classification:
Keylock Switches
Manufacturer:
ADDA USA
Description:
IC OFFLINE SWITCH FLYBACK 6TSOP
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Power Management (PMIC)
AC DC Converters, Offline Switchers
|
|
|
Manufacturer |
onsemi
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Output Isolation |
Isolated
|
|
|
Internal Switch(s) |
No
|
|
|
Voltage - Breakdown |
-
|
|
|
Topology |
Flyback
|
|
|
Voltage - Start Up |
18 V
|
|
|
Voltage - Supply (Vcc/Vdd) |
8.8V ~ 28V
|
|
|
Duty Cycle |
80%
|
|
|
Frequency - Switching |
65kHz
|
|
|
Fault Protection |
Over Power, Over Voltage, Short Circuit
|
|
|
Control Features |
-
|
|
|
Operating Temperature |
-40°C ~ 125°C (TJ)
|
|
|
Package / Case |
SOT-23-6 Thin, TSOT-23-6
|
|
|
Supplier Device Package |
6-TSOP
|
|
|
Mounting Type |
Surface Mount
|
|
|
Base Product Number |
NCP1251 |
