NB-PTCO-002

 Conforms to DIN EN 60751
 Wide operating temperature range:
-200°C to +600°C (Au-coated Nickel wire
and Class F 0.3, Ag-Wire versions are
limited to +300°C)
 Standard nominal resistances values:
R0: 100Ω and 1000Ω (others available
upon request)
 Standardized Tolerance Classes:
Class F 0.1 (T = AA), F 0.15 (A),
F 0.3 (B) and F 0.6 (C) accuracy with
defined tolerance temperature ranges
 Excellent long-term stability
 Fast response time due to low thermal
mass
 Variety of outline dimensions available to
fit a wide range of space requirements
 Global interchangeability
