MT28EW256ABA1HJS-0SIT

• Single-level cell (SLC) process technology • Density: 256Mb • Supply voltage – VCC = 2.7–3.6V (program, erase, read) – VCCQ = 1.65 - VCC (I/O buffers) • Asynchronous random/page read – Page size: 16 words or 32 bytes – Page access: 20ns – Random access: 70ns (VCC = VCCQ = 2.7-3.6V) – Random access: 75ns (VCCQ = 1.65-VCC) • Buffer program (512-word program buffer) – 2.0 MB/s (TYP) when using full buffer program – 2.5 MB/s (TYP) when using accelerated buffer program (VHH) • Word/Byte program: 25us per word (TYP) • Block erase (128KB): 0.2s (TYP) • Memory organization – Uniform blocks: 128KB or 64KW each – x8/x16 data bus • Program/erase suspend and resume capability – Read from another block during a PROGRAM SUSPEND operation – Read or program another block during an ERASE SUSPEND operation • Unlock bypass, block erase, chip erase, and write to buffer capability • BLANK CHECK operation to verify an erased block • CYCLIC REDUNDANCY CHECK (CRC) operation to verify a program pattern • VPP/WP# protection – Protects first or last block regardless of block protection settings • Software protection – Volatile protection – Nonvolatile protection – Password protection • Extended memory block – 128-word (256-byte) block for permanent, secure identification – Programmed or locked at the factory or by the customer • JESD47-compliant – 100,000 (minimum) ERASE cycles per block – Data retention: 20 years (TYP) • Package – 56-pin TSOP, 14 x 20mm (JS) – 64-ball LBGA, 11 x 13mm (PC) – 56-ball VFBGA, 7 x 9mm (PN) • RoHS-compliant, halogen-free packaging • Operating temperature – Ambient: –40°C to +85°C
