MCR1101-20-3

 AMR based integrated current sensor
 Superior Range & Accuracy
0.6% typical total error @25°C (MCR1101-20-3)
2.0% max error over temperature (MCR1101-20-3)
 Superior Frequency Response
1.5 MHz (typical 3dB BW)
 Fast output response time (300ns typical)
 Low Primary Resistance (0.9 mΩ)
 Single 3.3V Supply Operation
 Low power consumption (4.5mA typical)
 Overcurrent fault detection
 SOIC-16 package (RoHS/REACH compliant)
 -40 to +105°C Operating Temperature Range
 UL/IEC/EN60950-1 Certified
4.8 kV Dielectric Strength Voltage
1097 VRMS Basic Isolation Voltage
400 VRMS Reinforced Isolation Voltage
