LTC3115IFE-1#PBF
Part Number:
LTC3115IFE-1#PBF
Product Classification:
Keylock Switches
Manufacturer:
AEM Central Semiconductor
Description:
IC REG BUCK BOOST ADJ 20TSSOP
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - DC DC Switching Regulators
|
|
|
Mfr |
Analog Devices Inc. |
|
|
Series |
-
|
|
|
Packaging |
Tube
|
|
|
Part Status |
Active
|
|
|
Function |
Step-Up/Step-Down
|
|
|
Output Configuration |
Positive
|
|
|
Topology |
Buck-Boost |
|
|
Output Type |
Adjustable |
|
|
Number of Outputs |
1
|
|
|
Voltage - Input (Min) |
2.2V
|
|
|
Voltage - Input (Max) |
40V
|
|
|
Voltage - Output (Min/Fixed) |
2.7V |
|
|
Voltage - Output (Max) |
40V
|
|
|
Current - Output |
1A, 2A |
|
|
Frequency - Switching |
100kHz ~ 2MHz
|
|
|
Synchronous Rectifier |
Yes
|
|
|
Operating Temperature |
-40°C ~ 125°C (TJ)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
20-TSSOP (0.173", 4.40mm Width) Exposed Pad |
|
|
Supplier Device Package |
20-TSSOP-EP
|
|
|
Base Product Number |
LTC3115 |
