LT3086EDHD#TRPBF
Part Number:
LT3086EDHD#TRPBF
Product Classification:
Keylock Switches
Manufacturer:
AEM Central Semiconductor
Description:
IC REG LIN POS ADJ 2.1A 16-DFN
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
|
|
|
Mfr |
Analog Devices Inc. |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Output Configuration |
Positive |
|
|
Output Type |
Adjustable |
|
|
Number of Regulators |
1
|
|
|
Voltage - Input (Max) |
40V
|
|
|
Voltage - Output (Min/Fixed) |
0.4V
|
|
|
Voltage - Output (Max) |
32V |
|
|
Voltage Dropout (Max) |
0.54V @ 2.1A
|
|
|
Current - Output |
2.1A |
|
|
Current - Quiescent (Iq) |
2.4 mA
|
|
|
Current - Supply (Max) |
88 mA
|
|
|
PSRR |
80dB (120Hz)
|
|
|
Control Features |
Current Limit, Enable, Power Good, Tracking
|
|
|
Protection Features |
Over Current, Over Temperature, Reverse Polarity
|
|
|
Operating Temperature |
-40°C ~ 125°C
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
16-WFDFN Exposed Pad
|
|
|
Supplier Device Package |
16-DFN (5x4)
|
|
|
Base Product Number |
LT3086 |
