LS L29K-G1J2-1-Z
Part Number:
LS L29K-G1J2-1-Z
Product Classification:
LED Addressable, Specialty
Manufacturer:
AMX3D
Description:
LED RED DIFFUSED 0603 SMD
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Optoelectronics
LED Indication - Discrete
|
|
|
Mfr |
ams-OSRAM USA INC. |
|
|
Series |
SMARTLED® 0603 |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Color |
Red |
|
|
Configuration |
Standard
|
|
|
Lens Color |
Colorless
|
|
|
Lens Transparency |
Diffused
|
|
|
Millicandela Rating |
4.5mcd |
|
|
Lens Style |
Rectangle with Flat Top
|
|
|
Lens Size |
1.30mm x 0.80mm
|
|
|
Voltage - Forward (Vf) (Typ) |
1.8V
|
|
|
Current - Test |
2mA
|
|
|
Viewing Angle |
160°
|
|
|
Mounting Type |
Surface Mount |
|
|
Wavelength - Dominant |
630nm |
|
|
Wavelength - Peak |
643nm
|
|
|
Features |
-
|
|
|
Grade |
Automotive
|
|
|
Qualification |
AEC-Q101
|
|
|
Package / Case |
0603 (1608 Metric)
|
|
|
Supplier Device Package |
0603 |
|
|
Size / Dimension |
1.70mm L x 0.80mm W
|
|
|
Height (Max) |
0.65mm
|
|
|
Base Product Number |
LSL29K |
