LQH3NPZ100MMEL
Part Number:
LQH3NPZ100MMEL
Product Classification:
Pushbutton Switches - Hall Effect
Manufacturer:
AerosUSA
Description:
FIXED IND 10UH 800MA 228MOHM SMD
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Inductors, Coils, Chokes
Fixed Inductors
|
|
|
Mfr |
Murata Electronics |
|
|
Series |
LQH3 |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Drum Core, Wirewound
|
|
|
Material - Core |
Ferrite |
|
|
Inductance |
10 µH
|
|
|
Tolerance |
±20%
|
|
|
Current Rating (Amps) |
1.28 A |
|
|
Current - Saturation (Isat) |
-
|
|
|
Shielding |
Shielded
|
|
|
DC Resistance (DCR) |
228mOhm Max
|
|
|
Frequency - Self Resonant |
20MHz
|
|
|
Ratings |
AEC-Q200
|
|
|
Operating Temperature |
-40°C ~ 105°C
|
|
|
Inductance Frequency - Test |
1 MHz
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
1212 (3030 Metric)
|
|
|
Supplier Device Package |
1212 (3030 Metric)
|
|
|
Size / Dimension |
0.118" L x 0.118" W (3.00mm x 3.00mm)
|
|
|
Height - Seated (Max) |
0.059" (1.50mm)
|
|
|
Base Product Number |
LQH3NPZ |
