IRG4PC40UPBF
Part Number:
IRG4PC40UPBF
Product Classification:
Magnetic, Reed Switches
Manufacturer:
AIC tech
Description:
IGBT 600 V 40 A 160 W Through Hole TO-247AC
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Manufacturer |
Infineon Technologies
|
|
|
Series |
-
|
|
|
Packaging |
Bag
|
|
|
Part Status |
Obsolete
|
|
|
IGBT Type |
-
|
|
|
Voltage - Collector Emitter Breakdown (Max) |
600 V
|
|
|
Current - Collector (Ic) (Max) |
40 A
|
|
|
Current - Collector Pulsed (Icm) |
160 A
|
|
|
Vce(on) (Max) @ Vge, Ic |
2.1V @ 15V, 20A
|
|
|
Power - Max |
160 W
|
|
|
Switching Energy |
320µJ (on), 350µJ (off)
|
|
|
Input Type |
Standard
|
|
|
Gate Charge |
100 nC
|
|
|
Td (on/off) @ 25°C |
34ns/110ns
|
|
|
Test Condition |
480V, 20A, 10Ohm, 15V
|
|
|
Operating Temperature |
-55°C ~ 150°C (TJ)
|
|
|
Mounting Type |
Through Hole
|
|
|
Package / Case |
TO-247-3
|
|
|
Supplier Device Package |
TO-247AC
|
